FEATURES
FRONT SUSPENSION
- PRECISE AND PREDICTABLE – RAS 3 Front Suspension: High precision and highly predictable. The RAS 3 front suspension is designed to easily initiate a sidehill and track straight and true whether riding trees, carving meadows or riding the trail to your favorite playground.
PLATFORM
- THE MOST ADVANCED RIDE ON SNOW – REV Gen5 Platform: The next REVolution. Deep-snow specific design elements drastically elevate the ride with an inspiring appearance, reduced weight and improved technical performance to enhance the overall riding experience.
REAR SUSPENSION
- CARVES WITH YOU – tMotion X & tMotion XT rear suspensions: Two new suspensions that set the standard in deep snow agility and confidence. Refined geometry, weight savings and increased travel maximize ride quality in all conditions.
ROTAX ENGINES
- ENDLESS POWER – 850 E-TEC Turbo R: Summit snowmobiles are powered by one of two Rotax 2-stroke engines – including the most powerful factory-built 2-stroke turbo, the 850 E-TEC Turbo R at 180 hp. Each offers instant response and seamless power.
SHOT
- EASIEST STARTING – E-TEC SHOT Starter: Push-button starting with almost no added weight. After an initial pull-start, the engine charges an ultracapacitor. Pushing the handlebar SHOT button for subsequent starts uses energy stored in the ultracapacitor to turn the magneto into an electric motor that rotates the flywheel, and with E-TEC technology, starts the engine. Eliminates nearly 20 lb. (9 kg) compared to conventional electric start. SHOT starting is only possible with Ski-Doo-exclusive E-TEC technology.
SPECIFICATIONS
GENERAL INFORMATION
Manufacturer: Ski-Doo
Model Year: 2023
Model: Summit X Expert 165 850 E-TEC Turbo R SHOT PowderMax X-Light 3.0 HAC
Model Code: TJPB
Color: Platinum Silver / Manta Green
DIMENSIONS
Length: Overall – 129.9 in. (3,299 mm)
Height: Overall – 51.4 in. (1,306 mm)
Width: Overall – 42.5 to 43.7 in. (1,080 to 1,110 mm)
Weight: Dry – 456 lb.
ENGINE & DRIVETRAIN
Engine: 850 E-TEC TURBO R, two-stroke, turbocharged, eRAVE™
Cylinders: 2
Cooling: Liquid
Horsepower: 180 up to 8,000 ft.
Displacement: 849 cc
Bore x Stroke: 3.2 x 3.2 in. (82 x 80.4 mm)
Fuel System: E-TEC direct injection with additional booster injectors
Starting: SHOT
Drive Clutch: pDrive™ with clickers
Driven Clutch: QRS Vent Plus
Drive Sprocket: Pitch – 3.5 in. (89 mm)
Clutch Calibration: High Altitude
Reverse: RER™
Brakes: Brembo† with adj. lever
Fuel Type: Premium unleaded
Octane – 91
Fuel Capacity: 9.5 gal. (36 l)
Oil Capacity: 3.6 qt. (3.4 l)
OPERATIONAL
Platform/Frame: REV Gen5
Handlebar: Tapered with J-hooks/Grab handle
Riser block height – 4.7 in. (120 mm)
Instrumentation: Gauge – 4.5 in. digital display
Seating or Rider capacity: Deep-snow ultra-compact and lightweight
Skis: Pilot DS 4
Ski Stance: 34 in. (864 mm) adjustable
Carbide: 4 in.
Runner – Square 3/8
Track Type: PowderMax X-Light
Track LxWxH: 165 x 16 x 3.0 in.
OTHER
Additional Colors: Timeless Black
Platinum Silver / Manta Green: Includes
Heated throttle lever / grips: Bumpers (Front / Rear)
SUSPENSION
Shocks: Front – HPG† Plus with lightweight springs
Center – HPG Plus with lightweight spring: Rear – KYB† Pro 36 EA-3
Front Suspension: RAS 3
Travel – 8.2 in. (207 mm): Rear Suspension
tMotion XT: Travel – 10.4 in. (264 mm)
