Specs
Frameset
Frame
800 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, fender mounts, flat mount disc, 142x12mm thru axle
Fork Domane SLR carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, carbon dropouts, 12x100mm thru axle
Frame fit Endurance
Weight
Weight: 56 – 7.80 kg / 17.2 lbs
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
E-system
Battery: SRAM eTap battery pack (with charger)
Drivetrain
Shifter: SRAM RED eTap AXS, 12 speed
Front derailleur: SRAM RED eTap AXS, braze-on
Rear derailleur: SRAM RED eTap AXS, 36T max cog
SRAM RED AXS w/ power meter, 46/33, DUB, 165mm length
Size: 50, 52
SRAM RED AXS w/ power meter, 46/33, DUB, 170mm length
Size: 54, 56
SRAM RED AXS w/ power meter, 46/33, DUB, 172.5mm length
Size: 58, 60, 62
SRAM RED AXS w/ power meter, 46/33, DUB, 175mm length
Bottom bracket SRAM DUB, T47 threaded, internal bearing
Cassette: SRAM XG-1290, 10-33, 12 speed
Chain: SRAM RED D1, 12 speed
Max chainring size 2x: 52/36
Wheels
Wheel front: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle
Wheel rear: Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle
Skewer front: Bontrager Switch thru axle, removable lever
Skewer rear: Bontrager Switch thru axle, removable lever
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32mm
Size: 47, 50, 52, 54, 56, 58, 60, 62
Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x30mm
Tire part: Bontrager TLR sealant, 6oz
Rim strip: Bontrager Aeolus XXX rim strip
Max tire size: 38mm without fenders, 35mm with fenders
Components
Saddle Size: 47, 50, 52
Verse Short Pro, carbon rails, 155mm width
Size: 54, 56, 58, 60, 62
Verse Short Pro, carbon rails, 145mm width
Seatpost Size: 47, 50, 52, 54, 56
Domane carbon seatpost, KVF shaping, 20mm offset, 280mm length
Size: 58, 60, 62
Domane carbon seatpost, KVF shaping, 20mm offset, 320mm length
Bontrager Pro IsoCore VR-SF, 38cm
Size: 50, 52
Bontrager Pro IsoCore VR-SF, 40cm
Size: 54, 56
Bontrager Pro IsoCore VR-SF, 42cm
Size: 58, 60, 62
Bontrager Pro IsoCore VR-SF, 44cm
Handlebar tape Bontrager Supertack Perf tape
Trek: RCS Pro, -7 degree, 70mm length
Size: 50
Trek: RCS Pro, -7 degree, 80mm length
Size: 52, 54
Trek: RCS Pro, -7 degree, 90mm length
Size: 56, 58
Trek: RCS Pro, -7 degree, 100mm length
Size: 60, 62
Trek: RCS Pro, -7 degree, 110mm length
Brake SRAM Red eTap AXS hydraulic disc, flat mount
Brake rotor SRAM CenterLine X, centerlock, round edge, 160mm
Rotor size Max brake rotor sizes: 160mm front & rear
Accessories
Bag: Bontrager BITS Internal Frame Storage Bag
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice. Prices shown are manufacturer’s suggested retail prices.
Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
