Technical Specifications
FRAMESET
Frame: Specialized A1 Premium Aluminum, fully butted tubing, tapered head tube, PF30 BB shell , integrated ISCG 05 tabs, forged 10×135 horizontal dropouts, integrated chain tensioners
Seat Binder: Alloy, single-bolt, 34.9mm
Suspension
Fork: RockShox Pike DJ 26″, Solo Air spring, external rebound, charger damper, low-speed compression, 15x100mm Maxle® thru-axle, 100mm of travel
COCKPIT
Stem: Specialized P.Series, 4-bolt, 40mm
Handlebars: Specialized P.Series MTB Dirt, 6061 alloy, 9-degree backsweep, 6-degree upsweep, 38mm rise, 750mm width, 31.8mm clamp
Grips: Specialized P.Grip, lock-on
Saddle: P.Series Dirt, steel rails
SeatPost: Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm
BRAKES
Front Brake: SRAM Level T, hydraulic disc, 160mm
Rear Brake: SRAM Level T, hydraulic disc, 160mm
DRIVETRAIN
Cassette: Cr-Mo, 14t
Chain: KMC Z610, single speed, 1/2×3/32″
Crankset: Stout DJ, 30mm Cr-Mo spindle, 170mm
Chainrings: 30T
Bottom Bracket: PF30, 73mm shell
ACCESSORIES
Pedals: SBC-54 Flat Pedals
WHEELS
Rims: P.Series 26″ disc, 26.4mm internal width, 32h
Front Hub: P.Series Dirt Jump, sealed cartridge bearings, high-low flange, 15x100mm spacing, 32h
Rear Hub: P.Series Dirt Jump, sealed cartridge bearings, 10mm Cr-Mo axle, 32h
Front Tire: Specialized Rhythm Lite Control 26×2.3
Rear Tire: Specialized Rhythm Lite Control 26×2.3
Inner Tubes: Schrader, 40mm valve
WHEELS & TIRES
Spokes: Stainless, 14g
Weights based on production painted frames as pictured. Actual weights will vary based on colorway, frame size, and component variation. Specifications are subject to change without notice.
Geometry
| 22.5 | |
|---|---|
| Crank Length | 170mm |
| Handlebar Width | 750mm |
| Stem Length | 40mm |
| Saddle Width | 130mm |
| Seatpost Length | 200mm |
| Stack | 578mm |
| Reach | 423mm |
| Head Tube Length | 122mm |
| Head Tube Angle | 69.5° |
| BB Height | 322.5mm |
| BB Drop | 16mm |
| Trail | 83mm |
| Fork Length, Full | 490mm |
| Fork Rake/Offset | 40mm |
| Front Center | 678mm |
| Chainstay Length | 385mm |
| Wheelbase | 1063mm |
| Top Tube Length, Horizontal | 633mm |
| Bike Standover Height | 338mm |
| Seat Tube Length | 312mm |
| Seat Tube Angle | 70° |
